JDSU fiber inspection probe microscopes

HD3 Display Small Form-factor Display with 1.8-inch TFT LCD • High-resolution 1.8-inch TFT LCD display that can detect 1 μm or smaller scratches and dirt particles • Ruggedized enclosure for use in any environment • GripSwitch™ mode activates the display when held in-hand and deactivates when released, extending battery life • Built-in rechargeable NiMH battery pack • Over 3-hour run time on continuous-ON mode and extended run time in GripSwitch mode • Low-battery warning LED (illuminates when battery life is < 30 minutes) • AC adapter (100–240 VAC/12 VDC) charges NiMH battery and also acts as alternate power supply View clear detailed fiber end face images on 1.8-in video display • Use with JDSU probe microscope to inspect both bulkhead (female) and patch cord (male) sides of fiber interconnect • Promote proper fiber handling workflow and practice HD3 Display Specifications Dimensions 10 x 7.2 x 4.3 cm (3.9 x 2.8 x 1.7 in) Weight 230 g (8.1 oz) with probe Video display 1.8-in (45.7 mm) TFT LCD Connector 4-pin Hirose™ for FBP probes; hardwired to FBP or FBE probes Power source Built-in rechargeable NiMH (nickel metal hydride), 800mAH battery or AC adapter (100–200VAC/12VDC) Power modes ON (continuous on) GripSwitch (power saving mode) OFF/CHARGE Run time ~3 hours (continuous on) Extended run time with use of GripSwitch (power saving mode)
